Overview

Sandvik QJ341+ is an improved addition to our bestselling QJ341 jaw crusher range. This model comes with the added benefit of a double deck pre-screen as standard, while maintaining all of the features which made the original so popular.

The pre-screen will enable the removal of fines to increase your throughput resulting in greater efficiency, less wear on the crusher and ultimately higher productivity. This will be particularly effective in applications where you have a high proportion of fines in the feed material.

As with the standard model, Sandvik QJ341+ comes with features purposefully designed to provide the user with total control, such as the Sandvik PLC control system and control screen. With any equipment operator safety is vital, so this machine includes a self locking hopper, and can be set up from ground level.

Features and Benefits

• Hydraulically adjustable jaw setting to maximize your output
• Speed wheel fitted to main conveyor to stop the feeder, negating the need to dig out a heavily loaded conveyor
• Hydraulic drive enabling the crusher to start under load, minimizing downtime
• Steel pipe work used extensively to give superior heat dissipation and maximum reliability
• Premium components selected throughout and FEA analysis on structural parts for durability

Key Specifications

• Equipment: Single toggle C12 jaw crusher
• Feed Opening: 1200 x 750 mm / 47″ x 29″
• Optimum Feed Size: 650 mm / 25″ 6′
• Engine: C9.3B 280 kW / 375 hp , C9 261 kW / 350 hp
• Transport Length: 14.72 m / 48′ 3″
• Transport Width: 2.80 m / 9′ 2″
• Transport Height: 3.79 m / 12′ 5″
• Weight: 52,233 kg / 115,284 lbs
